Q70-39

Q70-39

GHz
Detailed specification
pdf, 203.74 KB
Demander un devis Сhargement

Features

DESCRIPTION
DescriptionQuanta 70 Q70-39, 70 GHz point-to-point unit, net throughput up to 480 Mbps, integrated dual-pol antenna, 39 dBi, 2x2 deg
Net throughputup to 480 Mbps
Recommended distancesup to 5 km
RADIO
Radio technologySC-FDE
Modulation coding schemesfrom BPSK 1/4 to QAM64 5/6
Transmit powerup to 11 dBm
Frequency range71000-76000 MHz
Channel width125 MHz
Antenna39 dBi
WIRED INTERFACES
Wired Interfaces1x Combo port GigabitEthernet/SFP
FORM FACTOR AND DIMENSIONS
Outdoor Unit (ODU) 255 x 226 x 189 mm, 3,1 kg
APPEARANCE

PACKING LIST
DescriptionPart NumberQuantity
Outdoor Unit
Power Supply
Power Cord
Cable Gland
Cable Gland
Standard RJ-45 connector
Shielded RJ-45 connector
RJ-45 Plug Cap
Mounting kit
Quick Start Guide
Q70-39
IDU-CPE-G
IEC C5
INFINET-GLAND-V3.1
INFINET-GLAND-V4
TPR-8P8C
8P8C-U-C5-SH
TPC-1G
MONT-KIT-85PW
-
1 pcs.
1 pcs.
1 pcs.
1 pcs.
1 pcs.
1 pcs.
1 pcs.
1 pcs.
1 pcs.
